CNG-1 Cylinder for Vehicle (seamless steel pipe made)

Standard: ISO11439:2000; ISO approved, Gost approved, BV approved;

OD(mm): Ф279mm, Ф356mm, Ф406mm, etc.

Water capacity: 50L, 65L, 70L, 80L, 100L, 110L, 120L, 145L, etc.

Cylinder length: 880mm, 930mm, 1054mm, 1060mm, 1110mm, 1145mm, 1230mm, 1300mm, 1385mm, 1660mm, 1760mm.

Material: 30CrMo, 34CrMo4

Pipe manufacturer: TPCO, CSST (ISO9809)

Design thickness(mm): 7.8mm, 8.8mm, etc

Working pressure：20Mpa

Testing pressure (time): 30Mpa (60S)

Service life: 15 years

Quality warranty: 15 years
