Description:
Diesel Generator
| Model | HGN3000SA | |
| Generator | Rated Frequency(HZ) | 50 |
| Rated Output Voltage(V) | 230 | |
| Rated Power Output(KVA) | 2.5 | |
| Max. Power Output(KVA) | 3 | |
| Power Factor(cosΦ) | 1 | |
| Method of Regulate Voltage | AVR / Capacitance | |
| DC Output | YES / NO | |
| Enine | Model | HS168F-2 |
| Type | Single cylinder, forced air cooled, 4-stroke, OHV, horizonal shaft. | |
| Fuel | 90# | |
| Bore×Stroke | 68mm×54mm | |
| Displacement(cc) | 196cc | |
| Compression Ratio | 8.5 :1 | |
| Type of Spark Plug | F7RTC | |
| Ignition System | T.C.I | |
| Starting System | Recoil / Electric | |
| Cooling System | Forced air cooling | |
| Maximum Power Output(kw/rpm) | 4.8/3600 | |
| Fuel Tank Capacity(L) | 15L | |
| Fuel Consumption(g/kw.h) | ≤395 | |
| Form of Carburetor | Floating type | |
| Oil | 15W/40SF | |
| Oil Capatity | 0.6L | |
| options | Engine Switch | YES |
| AC Circuit Breaker | YES | |
| DC Circuit Breaker | YES / NO | |
| Fuel Gauge | YES | |
| Oil alert System | YES | |
| Circuit Breaker Without Fuse | NO | |
| Triporate receptacle | 1 | |
| Accessory AC Plug | YES / NO | |
| Electric Starter | YES / NO | |
| 2-Wheel Dolly Kit | YES / NO | |
| Battery Tray | YES / NO | |
| Packing Dimension | Dimensions(L×W×H) | 680×500×525mm |
| Net Weight(kg) | 47 | |
| Gross Weight(kg) | 50 | |
| 20FT/40FT/40HQ with pallet Unit | 136/280/280 | |
| 20FT/40FT/40HQ without pallet Unit | 136/280/347 | |
| Certicfications | CE |
