Specification
1. Engine
Ignition mode:CDI
Compression ratio:9.1:1
Start mode:Electric or recoil start
Fuel tank capacity:6.6L
Transmission mode:Chain drive
Displacement:110cc
Power:5.5KW/8000r/min
Max.torque:6.7N.m/6000/rpm
Min.ground clearance:280mm
Max.speed 45km/h
Gas cylinder number:single
Bore and stroke:71x58mm

2. Chassis
Front wheels:19x7-8(28F)
Rear wheels:18x9.50-8 (33F)
Break type (F/R):F saucer/R drum
Front hanging:double
Rear hanging single arm-swing

3. Dimensions
Product dimensions :1550x1120x1100mm
Carton dimensions :1570x1135x1160mm
Height of seats:800mm
Wheel base:1070mm
Vehicle weight:150KG
Load capacity:170KG
Climbing angle:20°
Min.turning radius 2400mm
Max.number of riders1
