Brand:Ktm
Model:-
MOQ:1 Pieces
Send Inquiry
| Engine type | 1-cylinder 2-stroke engine, water-cooled, with reed intake and exhaust control |
| Displacement | 193 cm³ (11.78 cu in) |
| Bore | 64 mm (2.52 in) |
| Stroke | 60 mm (2.36 in) |
| Starting aid | Kick starter and electric starter |
| Gearbox | 6-gear, claw shifted |
| Primary transmission | 23:73 |
| Secondary ratio | 14:48 |
| Clutch | Multidisc clutch in oil bath/hydraulically activated |
| Ignition | Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan |
| frame | Central tube frame made of chrome molybdenum steel tubing |
| Fork | WP Suspension Up Side Down 4860 MXMA PA |
| Shock absorber WP Suspension PDS | 5018 DCC |
| Suspension travel Front | 300 mm (11.81 in) |
| Suspension travel Rear | 335 mm (13.19 in) |
| Brake system | Disc brakes, brake calipers on floating bearings |
| Brake discs - diameter Front | 260 mm (10.24 in) |
| Brake discs - diameter Rear | 220 mm (8.66 in) |
| Chain | 5/8 x 1/4" |
| Steering head angle | 63.5° |
| Wheelbase | 1,471±10 mm (57.91±0.39 in) |
| Ground clearance unloaded | 355 mm (13.98 in) |
| Seat height unloaded | 960 mm (37.8 in) |
| Total fuel tank capacity, approx. | 10 l (2.6 US gal) Super unleaded gasoline (95 octane), mixed with 2-stroke engine oil (1:60) |
| Weight without fuel, approx. | 99.5 kg (219.4 lb.) |
