Brand:SHUNDA
Model:CC cotton
MOQ:-0 -
Application:
Belt is suitable in chemical industry,electric power,metallurgy,light industry,foodstuff machining and coal mine.
Characteristics:
1.Good elasticity, anti-shock, anti-abrasive
2.High adhesion, good flexibility and trough ability;
3.Better stability of size and heat-resistance
4.Good water-proof ability, little change in strength under dry or wet conditions
Specification:
| Cover grade | Tensile strength | Elongation at break | Abrasion |
| Mpa | % | mm 3 | |
| H | 24 | 450 | 120 |
| D | 18 | 400 | 100 |
| L | 15 | 350 | 200 |
Adhesion and elongation of the belt
| Belt carcass | Adhesion strength | Elongation | |||
| Between plies N/mm | Between rubber and carcass | Longitudinal elongation at break % >= | Longitudinal elongation rate at reference load % <= | ||
| Rubber thickness<=1.5mm | Rubber thickness>1.5mm | ||||
| Cotton canvas | >=2.70 | >=2.4 | >=2.7 | 10 | 2.0 |
