PFA lined Ball valve Antistatic,full bore,ANSI flanges

salesatnjzhengyuancom

General :

->Operation Pressure: -0.1MPa~1.6MPa;

->Working Temperature: -10°C~180°C;

->Lining: temperature ≤120°C, choose FEP for Body and Bonnet;

             temperature 120°C~180°C, choose PFA for Body and Bonnet;

->Shell and Nodular cast ion: QT400-15, compliy with standard of GB/T12227;

->Installation and connection dimension:The structure length complies w ith the length standard through

negotiable selection in appendix A.5.3 0f HG/T3704.

->The flange connection dimension complies with  ISO7005-2 and  PN16 standards.

Besides, ANSI and BS standards are available by requirements.

Advantages:

->One Piece ball and stem PFA Lined full port, Blow-out proof .

->The lining of valve and ball can provide the general chemical corrosion-resistance materials as PFA & FEP by requirements.

->As for the innovative plate-type PTFE bellows filling structure, it can automatically adjust between the movable filling

   gland ring and spring tableting, and even though under the condition of heat-cool cycle, the filling always has high

   leak tightness and  reliability for pre-selection  loading.

->Even though on condition of frequent alternation between coldness and heat.

    it can realize the sealing effect for the flange of metal to metal mode.

->It has unified lining thickness in the sealing area to promote the ability for resisting the permeable media

->Strengthen the surface loading ability for labyrinth sealing through casting sealing lip. Carry long life PTFE valve seat.

->It adopts special spring valve seat design to ensure permanent leak tightness within the range of the entire

    pressure/temperature, including in condition of vacuum.

->It can choose the lining with antistatic property.

->PFA and FEP thermo-plastic valve lining with 3.5 mm's thickness, anti-seep, anti-corrosion and anti-vacuum.

->As for the high penetrability medium, it can adopt 5mm’s lining for the over-current part in the valve.
