Brand:CCSG
Model:ccsg-16
MOQ:50 Pieces
Application: Neon is often used in signs and produces an unmistakable bright reddish-orange light. Although still referred to as "neon", all other colors are generated with the other noble gases or by many colors of fluorescent lighting.
Neon is used in vacuum tubes, high-voltage indicators, lightning arrestors, wave meter tubes, television tubes, and helium-neon lasers. Liquefied neon is commercially used as a cryogenic refrigerant in applications not requiring the lower temperature range attainable with more extreme liquid helium refrigeration.
Both neon gas and liquid neon are relatively expensive – for small quantities, the price of liquid neon can be more than 55 times that of liquid helium. The driver for neon's expense is the rarity of neon, which unlike helium, can only be obtained from air.
The triple point temperature of neon (24.5561 K) is a defining fixed point in the International Temperature Scale of 1990.
Product Specification
| Name | Neon | CAS No. | 7440-01-9 |
| MF | Ne | EINECS No. | |
| Grade | Purity | Impurity content (ppm) | |
| 99.999% | O2<0.5, N2<2, CO<0.5, CO2<0.5, Ar<1, He<2, THC<0.1, Moisture<0.5 | ||
Physical Date
| Molecular Weight 20.18 g/mole | Boiling Point -410.9oF (-246.1oC) |
| Specific Volume 19.23 ft3/lbs at 70oF | Vapor Pressure @70oF (21.1oC) = Above the critical temp. of -379.8oF (-228.8oC) |
| Liquid Density at Boiling Point 75.35 lb/ft3 (1207kg/m3) | Gas Density at 70oF. 1 atm 0.0522 lb/ft3 (0.8362kg/m3) |
| Solubility In Water Negligible | Freezing Point -415.5oF (-248.6oC) |
| Evaporation Rate N/A (Gas) | Specific Gravity (Air=1) @70oF (21.1oC) = 0.70 |
| Appearance And Odor Colorless, odorless gas. | |
