Brand:oem
Model:7G512D004FT3-1311
MOQ:10 Pieces
Send Inquiry
| Item Model | 7G512D004FT3-1311 | |
| Measurement | 195*124*11mm | |
| Features | 3G Module bulit-in(compatible with 2G), support Bluetooth Voice-Call/GPS/BT/FM/WIFI,ATV | |
| Configuration Specification | ||
| Hardware Platform | MTK 6577 | |
| Operation System | Google Android 4.0 1.5GHz , DOULE CORE | |
| Telecommunication | Frequency Band System | 3G：WCDMA/EDGE/ |
| 2.5G：GSM/GPRS | ||
| Camera | Cam. Location | façade |
| pixels | The front with 0.3Mega，THE REAR WITH 2Mega | |
| type | CMOS | |
| Flash Light | SMT | |
| Hardware Configuration | Display screen | Dimension:7” |
| Resolution:SHD1024*600 | ||
| Type:TFT | ||
| TP | Multi-point Capacitive Touch Panel | |
| WiFi | Support（USB WiFi+RDA bluetooth module（voice call）） | |
| Bluetooth | Support BT 3.0HS+BT 4.0 LE | |
| FM | Support | |
| Vibration Motor | Support | |
| Audio Format | MP3、AAC、AAC+、EAAC+、AMR、WB-AMR、MIDI、Ogg Vorbis、PCM decode | |
| Video Format | ● Support SHD（720P）VIDEO decoding, H.264, H.263, VC-1, MPEG-1/2/4, | |
| ● Support H.264 Coding，720P@100fps. | ||
| ● Support universal music-play format,such as MP3，WMA，AAC etc. | ||
| RAM | Nand flash:4G(support up to 8G/16G) | |
| DDR3:128×4（512MB）/support up to 256*4(1GHZ) | ||
| Antenna | Built-in | |
| GPS | Support(embedded) | |
| G-SENSOR | Support（7660，8452） | |
| Battery | Voltage:3.7V | |
| Capacity: 3200mAh | ||
| ATV | Support | |
| I/O Interface | Earphone Interface | Standard 3.5mm port |
| Speaker | 2030mm*1 | |
| Extended RAM | Type:Plug & Play | |
| Capacity:32G | ||
| SIM Card | Support | |
| MIC | Support | |
| Power Jack | Support | |
| Function Key | 4pcs x Façade capacitive touch keys（HOME，ESCAPE, MUTE, search） | |
| 3pcs x flank buttons（power on/off & volume +/-） | ||
| Key Backlight | support | |
| Language-Version | Chinese/English | |
| others to be defined | ||
| Hand-Writing Input | Support | |
| Key-Board Input | soft key-board | |
| International Key-Board | Asia：China | |
| North America：America（English） | ||
| others to be defined | ||
| Entertainment | Audio-Plany | |
| Video-Play | ||
| E-Album | ||
| Accessories | 1pc charger/1pc data cable/1pc earphone cable/user manual/gift-box |
