MODEL

C1K

C2K

C3K

Rated Power

VA/W

1KVA / 0.7KW

2KVA / 1.4KW

3KVA / 2.1KW

Input

Nominal Voltage

120VAC

Voltage Range

85 ~ 150VAC

Frequency Range

46~54Hz(default), user adjustable within 40~60Hz

Power Factor

0.97

Connection

IEC320-10A inlet

IEC320-16A inlet

Output

Voltage

120VAC ± 2%

Frequency

50Hz ± 0.2Hz (Line mode)
50Hz ± 0.2Hz ( Battery mode)

Waveform

Sine Wave

Distortion

3%

4%

Overload Capability

108%~150% for 30 sec., ³150% for 300 ms

Current Crest Ratio

3:1

Connections

IEC320 * 4

IEC320 * 6

IEC320 * 3 and
Terminal Block

Battery

Type

Sealed, Maintenance free, Lead-Acid

Quantity

3 pieces

8 pieces

Back-up Time   (Full load)

5 min

9 min

5 min

with inside batteries.

Recharge Time

8 hrs to 90% of capacity after full load discharge

Transfer Time

0 ms; less than 4 ms from inverter to bypass and vice versa

Communication Interface

DB-9 Port

RS-232 Serial Interface

Intelligent Slot

Options: WebPower, AS400 Card or WinPower CMC

Network

Surge Protection

RJ45 I/O port available for network or Fax/Modem

Environmental

Operating Temperature

0 ~ 40°C

Operating Humidity

20 ~ 90% non-condensing

Physical

Net weight

13/6.3kg

30/12

30.5/13.5

G.W.

14.5/7.9

33.4/15.5

34/16.5

Body size(L*W*H)

144 *410*220mm

465 * 190 *350 mm

Packing size(1pc/1carton)

495 * 230 *321 mm

595 * 325 *473 mm

Loading

20'

750 pcs

300pcs

40'

1500 pcs

600pcs
