Brand:Roland
Model:-
MOQ:1 Pieces
Send Inquiry
| Printing / cutting method | Piezo ink-jet method / media-moving method | |
| Media | Width | 315 to 1,625 mm (12.4 to 64 in.) |
| Thickness | Maximum 1.0 mm (39 mil) with liner, for printing Maximum 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without liner, for cutting | |
| Roll outer diameter | Maximum 210 mm (8.3 in.) | |
| Roll weight | Max. 40 kg (88 lb.) | |
| Core diameter | 76.2 mm (3 in.) or 50.8 mm (2 in.) | |
| Printing / cutting width*1 | Max. 1,600 mm (63 in.) | |
| Ink cartridges | ||
| Types | 440-cc cartridge (cyan, magenta, yellow, black, light cyan, light magenta, light black) 220-cc cartridge (metallic silver, white) | |
| Colors | Seven colors (cyan, magenta, yellow, black, light cyan, light magenta, light black) or, Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, light black, white) or, Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, light black, metallic silver) or, Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, metallic silver, white) | |
| Printing resolution (dots per inch) | Maximum 1,440 dpi | |
| Cutting speed / Blade force | 10 to 600 mm/s (Media-feed direction: 10 to 300 mm/s) / 30 to 300 gf | |
| Cutting blade | Type: Roland CAMM-1 series compatible / Blade offset: 0.000 to 1.500 mm(0 to 0.059 in.) | |
| Software resolution (when cutting) | 0.025 mm/step | |
| Distance accuracy (when printing) *2*3 | Error of less than ±0.3 % of distance traveled, or ±0.3 mm, whichever is greater | |
| Distance accuracy (when cutting) *2 | Error of less than ±0.4 % of distance traveled, or ±0.3 mm, whichever is greater When distance correction has been performed (when the setting for [CUTTING MENU] - [CALIBRATION] has been made): Error of less than ±0.2 % of distance traveled, or ±0.1 mm, whichever is greater | |
| Repeatability (when cutting)*2*4 | ±0.1 mm or less | |
| Alignment accuracy for printing and cutting *2*5 | ±0.5 mm or less | |
| Alignment accuracy for printing and cutting when reloading media *2*6 | Error of less than ±0.5 % of distance traveled, or ±3 mm, whichever is greater | |
| Dryer unit | Heating type, setting range for the preset temperature: 30 to 55C° (86 to 130F°) | |
| Ink-fixing device *7 | Print heater / preheater, setting range for the preset temperature: 30 to 50C° (86 to 122F°) | |
| Connectivity | Ethernet (10base-T/100base-TX, automatic switching) | |
| Power-saving function | Automatic sleep feature | |
| Power requirements | AC 100 to 120 V ±10 %, 12 A, 50/60 Hz or AC 220 to 240 V ±10 %, 6.5 A, 50/60 Hz | |
| Power | During operation: Approx. 1,600 W / Sleep mode: Approx. 47 W | |
| Acoustic noise level | During operation: 65 dB (A) or less / During standby: 45 dB (A) or less | |
| Dimensions / Weight (with stand) | 2,948 (W) x 1,211 (D) x 1,260 (H) mm (116.1 (W) x 47.7 (D) x 49.6 (H) in.) / 205 kg (452 lb.) | |
| Environment | Power on | Temperature: 15 to 32°C (59 to 90°F) (20°C [68°F] or more recommended), humidity: 35 to 80%RH (non-condensing) |
| Power off | Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (non-condensing) | |
| Accessories | Exclusive stands, power cord, blade, blade holder, media clamps, media holder, replacement blade for separating knife, software RIP, User's Manual, etc. |
