Brand:Roland
Model:-
MOQ:1 Pieces
Send Inquiry
| Printing technology | Piezoelectric inkjet | |
| Media | Width | 259 to 1,625 mm (10.2 to 64 in.) |
| Thickness | Maximum 1.0 mm (39 mil) with liner | |
| Roll outer diameter | Maximum 210 mm (8.3 in.) | |
| Roll weight | Maximum 40 kg (88 lb.) | |
| Core diameter *1 | 76.2 mm (3 in.) or 50.8 mm (2 in.) | |
| Printing width *2 | Maximum 1,615 mm (63.6 in.) | |
| Ink cartridges | ||
| Types | Roland ECO-SOL MAX 2 440-cc cartridge | |
| Colors | Four colors (cyan,magenta,yellow,and black) | |
| Printing resolution (dots per inch) | Maximum 1,440 dpi | |
| Distance accuracy *3 | Error of less than ±0.3 % of distance traveled, or ±0.3 mm, whichever is greater | |
| Media heating system *4 | Print heater and preheater, setting range for the preset temperature: 30 to 45°C (86 to 112°F) Dryer, setting range for the preset temperature: 30 to 55°C (86 to 131°F) | |
| Connectivity | Ethernet (10base-T/100base-TX, automatic switching) | |
| Power-saving function | Automatic sleep feature | |
| Power requirements | AC 100 to 120 V ±10%, 11 A, 50/60 Hz or AC 220 to 240 V ±10%, 6 A, 50/60 Hz | |
| Power Consumption | During operation | Approx. 1350W |
| Sleep mode | Approx. 20 W | |
| Acoustic noise level | During operation | 62 dB (A) or less |
| During standby | 45 dB (A) or less | |
| Dimensions (with stand) | 2,750(W) x 800(D) x 1,295 (H) mm (108 (W) x 31 (D) x 50 (H) in.) | |
| Weight (with stand) | 177 kg (390 lb.) | |
| Environment | Power on | Temperature: 15 to 32°C (59 to 90°F) (20°C [68°F] or more recommended), humidity: 35 to 80%RH (non-condensing) |
| Power off | Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (non-condensing) | |
| Included items | Exclusive stands, power cord, media clamps, media holder, replacement blade for separating knife, software RIP, User's Manual, etc. |
- *1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 3 inches in diameter. To use 2-inch media rolls, the optional media flanges are required.
- *2 The length of the production run is subject to the limitations of the software program.
- *3 ·Media type: Media specified by Roland DG Corporation. ·Temperature: 25°C (77°F), humidity: 50% ·Roll media must be loaded correctly. ·Excluding expansion/contraction of the media ·Not assured when the pre-heater, print heater or dryer is used. ·All correction or adjustment functions of this machine have been made properly. ·Print travel: 1 m
- *4 ·Warm up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. ·Depending on the ambient temperature and media width, the preset temperature may not be reached.
