● Standard Serial ATA 2.6: SATA III, 6.0Gbps (Backward compatible with SATA 1.5 and 3.0Gbps)

● Form factor: 2.5 inch (100.0mmX70.0mmX9.0mm) L×W×H

● Connector: 7-pin signal segment and a 15-pin power segment

● Performance:

 -Max Sequential Data Read/Write: 520/500MB/s

 -Read/Write IOPS: 55,000 / 60,000 Access Time: 0.1ms

● Capacities:

32GB, 64GB, 128GB, 256GB, 512GB, 640GB (MLC)

32GB, 64GB, 128GB, 256GB, 512GB, 640GB (SLC)

● Power Management:

-Input voltage: 5V (±5%)

-Support Hot Plug/Removal Function

● Temperature ranges:

– Operation: 0~70°C (Standard)

– Storage: -50 to 95°C

● Intelligent features:

– Flash management algorithm: static and dynamic wear-leveling, bad block management algorithm

 – Supports dynamic power management and SMART (Self-Monitoring, Analysis and Reporting Technology)

– Supports BCH ECC 6~64bits in 1KBytes

– Support Power Failure Protection

– TRIM support

● MTBF: >3,500,000 Hours @25C

●Write endurance: >25 years @ 100GB write/ day (512GB MLC) Read endurance: unlimited
