HDMI to Ypbpr Audio with IC

Support 1080i /50HZ

PS: just can use on laptop ps3 Xbox360 to TV (DVD player not include)

Performance and characteristics

Conversion line can be used in set-top boxes, DVD and other equipment on the HDTV. It is an HDMI digital audio and video signals into analog Y / Pb / Pr color difference component and audio output device

1.Maximum support 1080P (1920 * 1080) resolution

2.Supporting HDCP

3.Installation fast, easy operate

4. Audio and video output

• Please use the original matching 5V power supply, To avoid the product burnt by the wrong power supply.

• Please do not put this product under high temperature, humid, dusty place.

• Please do not self-demolition of this Product, Don’t use alcohol, thinner or benzene to clean the surface of this product.

• To avoid falling or strong impact resulting in damage to products.

• The company reserves the right to improve products, product specifications and design subject to change without notice

Installation Steps

• Installed in accordance with connection diagram to connect, tune up display equipment (such as: TV) to YPrPb input state.

• The signal input device (such as: DVD, set-top boxes and other HDTV equipment) to HDMI output state, and adjust the output resolution (the highest support of 1080P (1920 * 1080)

Troubleshooting

Fault status Possible reasons

No power lights instructions Please check whether or not to connect power supply?

whether 5V input supply equipment it is normal?

No image display 1.Check products (Y / Pr / Pb) output to the display device is connected and the connection error?

2.Whether the display device to YPrPb input state.

3.Whether product support is higher than the maximum resolution of 1080P (1920 * 1080).
