15" touch screen monitor
2016-09-16 02:15 Views:45
Price:
0.00 USD/-
Brand:OEM
Model:CS-t1501
MOQ:-0 -
Send Inquiry
| Description:15″ Digital Touch Monitor Case/Bezel Colour: Black Panel: 15" A+ GRADE Panel Display Type: 4:3 Ratio Physical Resolution :1280*1024 OSD: Remote control OSD(Voice, Brightness, Contrast) One VGA input, 2 AV Input, 1 AV Input Input Video Format: Analog RGB ,NTSC/PAL/SCAME(AUTO) Touchscreen Interface: Serial (RS232) or USB 4- wires (5-wire)resistive touch-screen interface (USB port) Standard VGA input (15 pin D-SUB) can match with PC, GPS and security systems Two RCA video input can match with VCD, DVD and camera RGB input for navigation display (optional) Touch-screen for PC display (optional) USB/SD Optional FunctionConsumption: <30 W Typ Working Vplt:11V-15V Technical Specification: *Touch Response Time Serial/USB: 10.4ms *PowerSupply: 85-265VAC,50-60HZ *Pixel Pitch: 0.107 (W) X 0.372(H) mm *Pixel Response Time Rise + Fall (Typically): 12ms *Brightness: 400 cd/m2 *Contrast Ratio Typically: 14.58402778 *ViewingAngle Horizontal (left/right): 170° (85°/85°) * (From Centre, CR>=5) Vertical (up/down): 160° (70°/90°) *Temperature Range: Operating:-20℃-60℃, *Storage:-30℃-70℃ *Relative Humidity Non Condensing: Operating:10%-90%, Storage 5%-90% *FM/IR Range: FM-30-88.9 MHz, IR-2.3MHZ-2.8MHZ *TV Channel Parameter:VHF-L 48.25~170.00Mhz VHF-H 170.00~450.00Mhz |
| |
| |
| |
| |
| |
Quantity:3PCS/CTN Net Weight:14.5KG/CTN Gross Weight:15.5KG/CTN Carton:45X47X45CM |
| |
