Brand:Mingwei
Model:TC4810
MOQ:1 Sets
Send Inquiry
Technical parameters and detail technical tables of mechanisms
| Item | Unit | Magnification | |||
| α=2 | α=4 | ||||
| Rated load moment | KN.m | 540 | |||
| Max. load | t | 2 | 4 | ||
| Work radius | m | 3 – 48 | |||
| Load at max. radius | t | 1.0 | |||
| Radius at max. load | m | 27.3 | 14.79 | ||
| Hoisting height | IIndependent | m | 30 | ||
| Adhered | 120 | 60 | |||
| Outer size of whole crane | Chassis | m | 6.0×6.0 | ||
| Height of whole crane | Independent | 38.284 | |||
| Adhered | 128.284 | ||||
| Tip of jib to the slewing center | 48.74 | ||||
| Tip of balanced jib to slewing center | 11.425 | ||||
| Self-weight of whole crane | Independent | t | 21.41 | ||
| Adhered | t | 46.36 | |||
| Balanced weight | t | 8.0 | |||
| Other | Total power of motors | kW | 25.1 | ||
| Work grade at max. height | Grade | ≤6 | |||
| Allowable work temperature | -20～40 | ||||
