TOPKIT TOWER CRANE 236B
Max. Load: 10t
Jib length: 65m
Tip load: 2.05t
Free standing height: 59.7m
Mast section: 2.0*2.0*3.0m
Type: Stationary, inner-climbing, external climbing, travelling tower crane.
We supply our high quality tower cranes which are produced according to the advanced international tower crane technology. We assure the top quality, safety and high technical parameters of our products.
| Mechanisms | |||||||||
| m/min | t | m/min | t | drum | Ch-PS hp | KW | |||
| Hoisting | 2 falls | 4falls | |||||||
| 55RCS25 | 0-42-84 | 5/2.5 | 0-21-42 | 10/5 | 500m | 55 | 40.5 | ||
| 75LVF25 | 0-50-100 | 5/2.5 | 0-25-50 | 10/5 | 750m | 75 | 55 | ||
| Trolleying | 6D3V4 | 10-50(10t) 100(5t) | 6 | 4.4 | |||||
| slewing | RCV185 Optima+ | 0-0.8 tr/min rpm | 2×9 | 2×6.6 | |||||
| travelling | R≥10m | RT443 | 12.5-25 | 4×7 | 4×5.2 | ||||
| Main supply | CE138 IEC38 | 400V(+6%-10%) 50HZ | |||||||
| Necessary electric power | 75LVF: 100KVA 70RCS: 110KVA | ||||||||
| Generator set | |||||||||
| Consult us | |||||||||
