Brand:Minglong
Model:TC7040
MOQ:1 Sets
Send Inquiry
| TC7040 tower crane Technical Parameter | |||
| Jib length | 70 m | ||
| Mast Section | 2.5*2.5*3 m | ||
| Max. load | 16 t | ||
| Max. rated torque | 3150 KN. m | ||
| Tip load | 4.0 t | ||
| Hoisting height | Stationary | 50 m | |
| Achor | 205 m | ||
| Hoisting speed | a=2 | a=4 | |
| 80/40 m/min | |||
| Trolleying speed | 0-75 m/min | ||
| Slewing speed | 0.6 r/min | ||
| Climbing speed | 0.45 m/min | ||
| Upper chord of lifting beam | < 125 buckled square iron | ||
| Motors | Variable frequency motor | ||
| Materials of mast | < 200*22/< 200*20 splited structure | ||
| Parallel width of lifting beam | 1500 mm | ||
