Brand:Sanyisan
Model:PT5613
MOQ:1 Sets
Send Inquiry
Topless Tower Crane QTZ80P(PT5613)
1. The main stressed steel parts of QTZ80P(PT5613) topless tower crane use Q345B steel, size of mast section is 2m*2m*2.8m, splited mast section can save transportation fee.
2. Light weight, small air resistance, convenient transportation, slewing applies double slewing mechanisms, hoisting mechanism uses double-speed wound motors, run smoothly.
Properties and merits of Topless tower crane QTZ80P(PT5613):
1. Advanced manufacturing technique and quality management.
2. High working efficiency, great speed
| Topless Tower Crane QTZ80P(PT5613) | |||
| Rated lifting moment | KN. M | 800 | |
| Max. lifting load | T | 8 | |
| Working radius | M | 3~56 | |
| Tip load | T | 1.3 | |
| Hositing height | Independent | M M | 45 150 |
| Attached | |||
| Hositing speed | 2 falls | M/MIN | 80/40/10 |
| 4 falls | M/MIN | 40/20/5 | |
| Trolleying speed | M/MIN | 22/44 | |
| Slewing speed | R/MIN | 0.7 | |
| Climbing speed | M/MIN | 0.6 | |
| Structure self-weight | T | 45 | |
| Total installed capacity | KW | 43.5 | |
| Balance weight | T | 11.82 | |
| Working temperature | º C | -20~40 | |
| Working voltage | V | 380± %5 | |
| Max working wind pressure | N/M2 | 250 | |
