Brand:Sanyisan
Model:TC7052
MOQ:1 Sets
Send Inquiry
TC7052 tower crane
Max. Load: 25t
Jib length: 70m
Tip load: 5.2t
Free standing height: 51m
Max. Height: 200m
Mast section: 2.5*2.5*3.0m.
| TC7052 tower crane Technical Parameter | |||
| Jib length | 70 m | ||
| Mast Section | 2.5*2.5*3 m | ||
| Max.load | 25 t | ||
| Max. rated torque | 4000 KN.m | ||
| Tip load | 5.2 t | ||
| Hoisting height | Stationary | 51 m | |
| Achor | 200 m | ||
| Hoisting speed | a=2 | a=4 | |
| 80/40 m/min | |||
| Trolleying speed | 0-100 m/min | ||
| Slewing speed | 0.62 r/min | ||
| Climbing speed | 0.46 m/min | ||
| Upper chord of lifting beam | <125 buckled square iron | ||
| Motors | Variable frequency motor | ||
| Materials of mast | <140*14 fastener/manganese steel | ||
| Parallel width of lifting beam | 1500 mm | ||
