Brand:Sanyisan
Model:TC 6518
MOQ:1 Sets
Send Inquiry
| | QTZ160(TC7010) | QTZ160(TC6518) | ||
| Rated lifting moment | KN.M | 1600 | 1600 | |
| Max. load | T | 10 | 10 | |
| Working range | M | 2.5-70 | 2.5-65 | |
| Rated lifting capacity | T | 1.0 | 1.8 | |
| Hositing height | Independent | M | 53 | 53 |
| Attached | M | 200 | 200 | |
| Hositing speed | 2 falls | M/MIN | 100/50 | 100/50 |
| 4 falls | M/MIN | 50/25 | 50/25 | |
| Trolleying speed | M/MIN | 60/30/8.4 | 60/30/8.4 | |
| Slewing speed | R/MIN | 0.56 | 0.56 | |
| Climbing speed | M/MIN | 0.5 | 0.5 | |
| Structure self-weight | T | 70 | 70 | |
| Total installed capacity | KW | 53 | 53 | |
| Balance weight | T | 24 | 24 | |
| Working temperature | Degree | -20~40 | -20~40 | |
| Working voltage | V | 380±%5 | 380±%5 | |
| Max working wind pressure | N/M2 | 250 | 250 | |
