Brand:Keming
Model:KSP-9
MOQ:1 Sets
Introduction
* KSP-9 Wet Shotcrete Machine
* for half wet or wet concrete spraying
Performance Features
*including driving device, rotor assembly, sealing system, vibration hopper, air system, spraying system, accelerator conveying system and electric control system
*concrete mixture gets well mixed & water and cement ratio is accurately controlled
*quicker cement hydration, fewer dusts, lower rebound rate, good mixing uniformity and high concrete strength
*reasonable structure, stable performance, convenient operation and maintenance, long service life
Application Scope
*tunnel, culvert, subway, hydroelectric works, underground works and mine laneway.
Technical parameters
| Capacity | 7~9m³/h |
| Conveying distance | 30m(WET)/200m(DRY) |
| Max. aggregate size | 20mm |
| Concrete slump | 8~15cm |
| Conveying Pipe ID. | 51mm/64mm |
| Rebound rate | ≤10%(on average ) |
| Rated working pressure | 0.3-0.6Mpa |
| Air consumption | 9-10m³/min |
| Motor power | 7.5kw |
| Max. Pump discharge of accelerator | 35-200L/h |
| Voltage rating of accelerator | 0.6Mpa |
| Voltage | 380V/660V |
| Dimension | 2100*900*1200(mm) |
| Weight | 1200kg |
