²  Input voltage: AC24V(±10%),50/60Hz

²  Power consumption: Heater ≤60W   Fan ≤2W

²  IP standard: IP66

²  Automatic temperature control:

Heater:

On: 5 ±5℃

Off: 15±5℃

Fan:

On: 40±5℃

Off: 25±5℃

²  Mode of opening upper cover:Top-opened gas spring knighthead

²  Material :

Body: aluminum alloy

Viewing window: optical glass

Lock catch: stainless steel

²  Operating ambient temperature: -35 to 65℃(with Heating elements)

²  Operating ambient humidity: ＜90%(without condensing agent, under heating conditions)

²  Viewing window: 100 (W)x 90(H)mm,double window

²  Maximum size of equipment installation:

Both sides of the space: 270(L) x 93(W) x 130(H)mm

²  Recommend pan tilt: J-PT-2118-D, J-PT-2215-DL,J-PT-7230-DL

²  Optional: heater, fan, sunshield and wiper

²  Installation environment:Outdoor

²  Weight：7.2kg
