Compression H.264 High Profile

Dual stream 720P/D1

Image resolution Max:1280*720

Lens 6mm@F1.8(8mm,12mm optional)

Lens mount CS

Adjust Angle Level:0°~355°, Vertical:0°~80°, Rotation:0°~140°

IR-CUT Support

Min. Illumination Color:0.6Lux/ @(F1.2 AGC ON),0 Lux with IR                                                                      B/W:0.08 Lux @(F1.2,AGC ON),0 LUX with IR

IR distance 20~30meters

frame rate 30fps(1280*720)

Protocol HTTP,TCP/IP,UDP,RTSP etc...

Storage Network and SD card(optional)

Video output 1ch BNC,1 x network

Power supply DC12V±10%

Operating Condition -10℃～60℃

Weight 500g

Size Φ124x109.1mm
