Brand:Xinming Boshi
Model:xms-7608SD
MOQ:1 Pieces
Send Inquiry
| Compression standard | H.264 |
| Video input | BNC（1.0V p-p/75Ω）×8-channel |
| Video output | BNC（1.0V p-p/75Ω）×1-channel |
| VGA×1,800×600,1024×768,1280×1024 | |
| HDMI×1,resolution max to 1920*1080p | |
| Audio input | RCA（2.0Vp-p/600Ω）×1 |
| Audio output | RCA（600Ω）×1 |
| Display resolution | D1 |
| Playback resolution | 8D1/1D1,2(960H)+6CIF/2(960H)+6CIF |
| frame rate | 0.1F/S-25F/S（PAL） 0.1 F/S-30 F/S（NTSC） |
| Stream set | Adjustable five-speed stream |
| HDD | 1SATA |
| Network interface | 10/100M |
| USB interface | USB2.0*2 |
| RS485 interface | 1 |
| Power supply | DC12V/2A |
| Power(without HDD) | ≤15W |
| Work temperature | -10℃- +55℃ |
| Humidity | 10%-90% |
