Brand:Xinming Boshi
Model:xms-7616KD
MOQ:1 Pieces
Send Inquiry
| Compression standard | H.264 |
| Video input | BNC（1.0V p-p/75Ω）×16-channel |
| Video output | BNC（1.0V p-p/75Ω）×1-channel |
| VGA×1,800×600,1024×768,1280×1024 | |
| HDMI×1,resolution max to 1920*1080p | |
| Audio input | RCA（2.0Vp-p/600Ω）×4-channel |
| Audio output | RCA（600Ω）×1-channel |
| Display resolution | D1 |
| Playback resolution | 2D1+14CIF recording and 2D1+6CIF playback |
| frame rate | 0.1F/S-25F/S（PAL） 0.1 F/S-30 F/S（NTSC） |
| Stream set | Adjustable five-speed stream |
| HDD | 2SATA |
| Network interface | 10/100M |
| USB interface | USB2.0*2 |
| RS485 interface | 1 |
| Alarm Input | 2CH（Switch） |
| Alarm output | 1CH（Switch） |
| Power supply | DC12V/3A |
| Power(without HDD) | ≤15W |
| Work temperature | -10℃- +55℃ |
