Compression H.264 High Profile

Dual stream 720P/D1

Image resolution Max:1280*960

Lens 6mm@F1.8(4.2mm,8mm,12mm optional)

Lens mount CS

Adjust angle Level:0°~355°, Vertical:0°~75°

IR-CUT Support

Min. Illumination:

Color:0.01Lux @ (F1.2,AGC ON),0 LUX with IR

B/W:0.01Lux @ (F1.2,AGC ON),0 LUX with IR"

IR distance 20~30meters

frame rate 30fps(1280*720),22fps(1280*960)

Protocol HTTP,TCP/IP,UDP,RTSP etc...

Storage Network

Video output 1ch BNC,1 x network

Waterproof & dustproof IP66, vandal-proof

Power supply DC12V±10%

Operating Condition -10℃～60℃

Weight 700g
