Brand:SXK
Model:SXK-Y6-5-1-1-1-1
MOQ:100 Sets
Send Inquiry
- Self-intellectual property
- Supports (EPC C1G2) protocol tag
- 902 to 928MHz frequency band (optional)
- FHSS or fix frequency transmission
- RF output power up to 30dBm (adjustable)
- 8 and 12dBi antenna optional with effective distance up to 3and 10m
- Supports auto-running, interactive and trigger-activating workmode
- Low power dissipation with single 9V DC power supply
- Supports RS232, RS485 and Wieg and interface
- Effective distance depends on antenna, tag and environment
- Designed upon fully self-intellectual property
- based on proprietary efficient DSP algorithm, supports fast tagread/write operation with high identification rate
- Widely used in RFID application systems such as logistics,access control, anti-counterfeit and industrial production processcontrol system
- Interface:
- Red: 9V
- Black: ground
- Yellow: Wiegand data 0
- Blue: Wiegand data 1
- Purple: RS485 R+
- Orange: RS485 R-
- Brown: ground
- White: RS232 RXD
- Green: RS232 TXD
- Gray: trigger input (TTL level)
- Optional model named as UHF reader18TCP with TCP/IP interfacealso available
