Brand:CMOLO
Model:CPW-322ES
MOQ:1 Pieces
Send Inquiry
New design swing gate turnstile CPW-322ES is with fine workmanship and intelligent functions.
Product specification:
1-The turnstile housing is made of stainless steel, seamless design.
2-The internal structures are all under rustproof processing, so the turnstile will be durable.
3-The machine works smoothly without any noise.
4-The swing can be pushed freely when the power is off, and it can be the emergency passageway.
5-The system adopts standard electrical interfaces.
6-Compatible with all main access control card readers
7-Be suitable for the different security grade access control passageways
8-To effectively prevent the illegal person entering and exiting
| Technical Parameters | |||
| power and voltage | AC 220V / AC 85 ~ 230V | operation voltage | DC 24V |
| machinery mechanism | MTHT™ Lossless mechanism | driving motor | DC brushless motor |
| communication interface | RS485 / RS232 | ||
| control input/output | 6 channels switching value output (12V and 24V dry contact signals) / 4 channels switching value input (pulse width is not less than 100ms; driving current is not less than 10mA; and the high and low electrical level difference value is 5-36V DC electrical level signal) | ||
| passing speed | 30 ~ 45 people / min | working environment | Indoors |
| operation temperature | -15 ~ 60 Centigrade | humidity temperature | 0 ~ 95% (non-condensation) |
