Brand:CMOLO
Model:CPW-900ETS01
MOQ:1 Pieces
CMOLO swing gate turnstile model: CPW-900ETS01, slim and special.
Product Description: The swing gate can be pushed freely when the power is off.
The housing is made of the high quality stainless steel, and it is seamless design. The internal structures are all under rustproof processing, so it will be durable. The machine works smoothly without any noise.
The system adopts standard electrical interfaces, compatible with all main access control card readers (Including but not limited to magnetic card reader, barcode card reader, ID card reader, IC card reader etc and biological features card reader, such as fingerprint reader, iris reader, face recognition reader etc. ), it is suitable for the different security grade access control passageways, to effectively prevent the illegal person entering and exiting.
| Technical Parameters | |||
| power and voltage | AC 220V / AC 85 ~ 230V | operation voltage | DC 24V |
| machinery mechanism | MTHT™ Lossless mechanism | driving motor | DC brushless motor |
| communication interface | RS485 / RS232 | ||
| control input/output | 6 channels switching value output (12V and 24V dry contact signals) / 4 channels switching value input (pulse width is not less than 100ms; driving current is not less than 10mA; and the high and low electrical level difference value is 5-36V DC electrical level signal) | ||
| passing speed | 30 ~ 45 people / min | working environment | Indoors |
| operation temperature | -15 ~ 60 Centigrade | humidity temperature | 0 ~ 95% (non-condensation) |
