Swing Gate Turnstiles CPW-622CS

All-around Personal Safety Protection

       The turnstile opens automatically to evacuate people in the event of an emergency, such as fire, power failure, etc.
       Infrared and mechanical anti-clamping functions provide double protection.
       The gate can be pushed slowly when a sudden impact force is applied beyond the safety range so as to protect the
       machine and the pedestrian effectively.
       All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current
       protective device to effectively avoid electric shocks.

Intelligent & Advanced Passageway Security Concept
       The matrix type photoelectric stereoscopic detection technology is adopted to sensitively detect the behaviors that
       threaten the passageway safety, such as illegal intrusion, reverse passing, tail-gating, and give out alarms through
       sound, light, etc. The turnstile can be also linked with other security systems.

Strong & Stable Control Core
       High-quality DC brushless motor is configured and advanced servo control system is carried to truly achieve precise
       control, stable performance and maintenance-free.
       Lossless mechanism structure based on German technology is adopted to ensure long lifespan.

Dimension, Material & Surface Finish
        Stainless steel thickness of the cabinet: customized within 1.5~3.0mm.
        Lane width: 1200mm is at the maximum, but the lane depth may be changed accordingly.
        Material of the cabinet: 304 / 316 grade stainless steel.
        Material of the swing gate: tempered glass / organic glass / polycarbonate, and color can be customized.
        Surface finish of the cabinet: satin finish / polishing / frosted finish / electroplating / baking finish.


System Integration
        Integrate with access control system required by customers, and built-in reader appointed by customer.
        Integrate with visitor management system.
        Integrate with ticketing system.

Direction Indicator
        The installation position of direction indicator can be adjusted.
        The pattern of direction indicator can be customized.
