Brand:CMOLO
Model:APW-Aquaeco
MOQ:1 Pieces
| Technical Parameters | |||
| power and voltage | AC 220V / AC 85 ~ 230V | operation voltage | DC 24V |
| machinery mechanism | MTHT™ Lossless mechanism | driving motor | DC brushless motor |
| communication interface | RS485 / RS232 | rated power | 100W |
| passing speed | 30 ~ 45 people / min | working environment | Indoors |
| operation temperature | - 15 ~ 60 Centigrade | humidity temperature | 0 ~ 95% (non-condensation) |
| control input/output | 6 channels relay control output/ 4-channel dry contact signal input | ||
All-around Personal Safety Protection
The turnstile opens automatically to evacuate people in the event of an emergency, such as fire, power
failure, etc.
Infrared and mechanical anti-clamping functions provide double protection.
The gate can be pushed slowly when a sudden impact force is applied beyond the safety range so as to protect the
machine and the pedestrian effectively.
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current
protective device to effectively avoid electric shocks.
Intelligent & Advanced Passageway Security Concept
The matrix type photoelectric stereoscopic detection technology is adopted to sensitively detect the
behaviors that threaten the passageway safety, such as illegal intrusion, reverse passing, tail-gating,
and give out alarms through sound, light, etc. The turnstile can be also linked with other security systems.
Strong & Stable Control Core
High-quality DC brushless motor is configured and advanced servo control system is carried to truly achieve precise
control, stable performance and maintenance-free.
Lossless mechanism structure based on German technology is adopted to ensure long lifespan.
Dimension, Material & Surface Finish
Stainless steel thickness of the cabinet: customized within 1.5~3.0mm.
Lane width: 1200mm is at the maximum, but the lane depth may be changed accordingly.
Material of the cabinet: 304 / 316 grade stainless steel.
Material of the swing gate: tempered glass / organic glass / polycarbonate, and color can be customized.
Surface finish of the cabinet: satin finish / polishing / frosted finish / electroplating / baking finish.
System Integration
Integrate with access control system required by customers, and built-in reader appointed by customer.
Integrate with visitor management system.
Integrate with ticketing system.
Direction Indicator
The installation position of direction indicator can be adjusted.
The pattern of direction indicator can be customized.
