1.Dimension of main froming machine:9.0m(L)*1.5m(W)*1.3m(H)

2.Total weight:about 7T

3.Main motor power:380V 50HZ,18.5KW.orign:Mengniu Hengshui

4.Reducer:cycloidal planetary speed reducer..Origin:Jiangsu changzhou

5.Material of structure::GB 350mmB type”I” steel,orign:tangshan

6.Chains :GB45# steel quenched,1.5inch doule row

7.Thickness of mid-plate:18mm,orign:Shougang Beijing

8.Material shaft:45# steel,diameter:80mm, Quenched after the finished form.orign:Shougang Beijing

9.Leveling machine:9 roller flatteing,diameter of roller:110mm,usingφ114mm wall thickness

15m 45# seamless steel tube,finish maching,hard chrome plating on surface.

10. Die roller:all adopt Gr15(ball bearing steel),through hammer,finish machining,quenching(hardness: 50°~52°),

line cutting at the keyway,then hard chrome plating on surface.max diameter: φ45mm

11. Adjust set:adopt 45#steel, seaming steel tube through finish maching,line cutting cut snaps forming.

12. Roller:10 axis

13. Auxiliary wheel:7 rows adjustment auxiliary wheel.

14. Adjustment method:rotary adjusting device

15. Specification of Z purlin machine:adjust width(80-300mm) wall height(40-80mm)

16. Thickness of plate:2-3mm

17. Working speed:3-10m/min
