Brand:YINHUA
Model:MMLX-8/12/16/20
MOQ:1 Sets
Features of MMLX-16 Polishing Machine For Marble Slab
It adopts PLC terminal control system; operator can set the parameters by the programmable controller with LCD screen. It is equipped with trouble alarm and abrasive block consumption alarm systems. It is qualified for continuous grinding and polishing marble stone slabs. The speeds of work piece conveyor and cross beam adopt converters to adjust their speed. Its processing width and working pressure of grinding heads are adjustable. Each grinding head can rise and fall automatically following the work piece movement.
Specifications
| Name | Unit | MMLX-16 |
| No. of head | n | 16 |
| Useful working width | mm | 600-2000 |
| Useful working thickness | mm | 15-50 |
| Belt advancement speed | mm/min | 0-2200 |
| Spindle motor power | kw | 11 |
| Total power | kw | 181 |
| Water consumption | M2/h | 25 |
| Dimension（L×W×H） | mm | 12690×2700×2650 |
