Brand:Mars
Model:-
MOQ:1 Pieces
3D CNC Stone Engraving Machine with 6 Heads
Applicable Scope：
Widely used for the processing of marble, Shoushan stone, granite, bluestone, jade, crystal, stone tablet, agate, ink stand, copper sheet, aluminum sheet, etc.
Performance Features：
1. imported linear square rails, double-row four-column ball bearing slide blocks, big loading capacity, smooth operation, high precision, long life.
2. High-power double spindles, strong power.
3. Advanced numerical control system, simple operation, easy maintenance, CNC dividing head optional, user-friendly design can meet the diverse needs of customers;
4. Good compatibility. It is compatible with any advanced CAD/CAM software, such as Type3/ ArtCAM/ CAXA/ UG / pro-e/ Mastercam/ JD/ Wentai, etc..
5. All of our models can be customized according to customer requirements.
Technical Parameters:
| Model | 1325 | 1825 | 2025 | 2030 |
| Working Stroke | 1300*2500mm | 1800*2500mm | 2000*2500mm | 2000*3000mm |
| Z Axis Working Stroke | 100mm | |||
| Spindle Power | 3KW/ 4.5W/ 5.5KW frequency air-cooling spindle （Air-cooling motor, or Italy imported HSD/ELTE/ Colombia motor is optional） | |||
| Max Motion Speed | 25 m/min | |||
| Max Proceeding Speed | 15 m/min | |||
| Spindle Rotational Speed | 0-24000 rpm/Min | |||
| Engraving Tool | Φ3.175mm, Φ4mm, Φ6mm, Φ12.7mm | |||
| Dictate Format | G-Code / HPGL | |||
| Resolution | 0.01mm | |||
| Controlling System | NC Studio (DSP) | |||
