Can press various sorts of decorateing  onto plywood, joiner's boards, MDF board and so on.

Can finish furniture production process.

Can reduce labor cost, earn more profit.

Layers(opens):3
Distance between press plates:100mm
Oil cylinder diameter: Φ100mm
Oil cylinder stroke: 350mm
Maximum temperaturu of the press board: 120℃
Press board size: 2500×1300×42mm
Maximum pressure:120T
Number of oil cylinders:8pcs
Fuel tank capacity quantity: 60L
Capacity of the oil tank: 100L
Installation power:7.7kw
Heat equipment power: 48kw
Weight: 7500kg
Overall dimension: 3750×1650×2150mm
