Zinc Coated Steel Strip For Shutter Windows(Steel Tape)

Mother steel coil were splitted in to many narrow steel, also called steel strips, steel strapping, steel tapes...

1. Reference Standard: JIS G3302-1998, EN10142-2000, GB/T2518-2004, ASTM A653M
2. Steel grade: DX51D, Q195, Q235, 08Al, SPHC
3. Thickness: 0.18mm - 0.9mm
4. Width: 45mm - 600mm
5. Surface finishes: Minimum spangle, regular spangle, chromatic, un-oiled and oiled
7. Inside diameter: 200, 250, 300, 350, 450, 508 and 610mm
8. Coil weight: 200 to 7, 000kg
9. Material strength (normal):
Yield: 280 to 350Mpa
Tensile: 380 to 450Mpa
10. Applications:
(1) Pre-galvanized steel tubes and pipes.
(2) Galvanized steel channels and profiles.
(3) Armoring cable.
(4) Construction, the manufacturing of cars, ships, containers and household electric appliances, other industries usage.
