12*16mm Soft PVC Water Hose

Detail
1.Application:Convey water,oil,weak chemical and other liquid.
2.Tube:Flexible PVC
3.Reinforcement:High tensile synthetic fibre spiraled
4.Characteristics:Green color,flexible,glossy.Its of good resistance to weather ,ozone and ultraviloet light
5.Temperature range:-5℃~+65℃

Specification
1.Inside diameter
inch:3/8",1/2",5/8",3/4",1"
mm:10;12,13,13;15,16,16;19,19;25,25

2.Outside diameter(mm)
14;16,17,18;20,20,21;24,25;30,31

3.Wall(mm)
2.0;2.0,2.0,2.5;2.5,2.0,2.5;2.5,3.0;2.5,3.0

4.Working pressure(Mpa)
0.7;0.6,0.5,0.6;0.7,0.5,0.7;0.6,0.7;0.5,0.6

5.Burst pressure(Mpa)
2.1;1.8,1.5,1.8;2.0,1.6,2.0;1.8,2.1;1.5,1.8

6.Length(m)
100;100,100,100;50,50,50;50,50;50,50

7.Weight(kg/m)
0.098;0.115,0.123,0.159;0.179,0.147,0.189;0.220,0.270;0.281,0.343

8.Packing measurement D*H(mm)
460*130;500*190,500*190,500*190;430*180,430*180,430*180;500*180,500*180;580*170,580*170
