Electric Cable Protection Tube

Detail:
1.Application:Widely used for conveying water,oil,weak chemicals and other liquids under low pressure condition in foodstuff,sanitary,industry,agriculture and aquatic animals equipment etc.
2.Tube:Made from non-toxic clear flexible pvc
3.Characteristics:Flexible,transparent and corrosion resistant with applications are widely
4.Temperature range:-5℃~+65℃

Specification:
1.Inside diameter
inch:1/4",5/16",3/8",1/2",5/8"
mm:6;8;10;12;15

2.Outside diameter(mm):8;10;12;15;18

3.Wall(mm):1.0;1.0;1.0;1.5;1.5

4.Working pressure(Mpa):
0.15;0.15;0.15;0.1;0.1

5.Burst pressure(Mpa):
0.45;0.4;0.4;0.3;0.3

6.Length max.(m):100;100;100;50;50

7.Weight(kg/m):0.029;0.037;0.045;0.083;0.101

7.Packing measurement D*H(mm):380*110;400*100;420*110;120*120;420*130
