Flexible PVC Gas Cooker Hose Pipe

Detail:
1.Applications:Mainly used for conveying of gas for household fuel gas system .
2.Tube:Flexible pvc
3.Reinforcement:High tensile synthetic yarn braided or spiraled .
4.Cover:Flexible pvc
5.Characteristics: Weather resistant and zone resistant .Its of pressure bearable ,flexible ,light in weight ,anti-bending ,less distortion and nice smooth surface.
6.Standard length:50m,100m.
7.Temperature range:-5℃~+65℃

Specification:
1.Inside diameter
inch:5/16",3/8"
mm:8,8.5,8.5;9,10

2.Outside diameter(mm):14,14,14.5;15,16

3.Working pressure(Mpa):
2.0,2.0,2.0;2.0,2.0

4.Burst pressure(Mpa):
6.0,6.0,6.0;6.0,6.0

5.Length max.(m):100,100,100;100,100

6.Weight(kg/m):0.135,0.127,0.141;0.147,0.160

7.Packing measurement D*H(mm):500*140,500*140,500*140;520*140,520*140
