Brand:Ritia
Model:a234
MOQ:2 Long Ton
sch 20 carbon steel pipe fittings equal tee
More: http://www.tubeandfitting.com/461/sch20-equal-tee.html
| Nominal Diameter | Outside Diameter | Center to End | |||||
| D1 | D2 | ||||||
| DN | NPS | Series A | Series B | Series A | Series B | C | M |
| 200×200×200 | 8×8×8 | 219.1 | 219 | 219.1 | 219 | 178 | 178 |
| 250×250×250 | 10×10×10 | 273.0 | 273 | 273.0 | 273 | 216 | 216 |
| 300×300×300 | 12×12×12 | 323.9 | 325 | 323.9 | 325 | 254 | 254 |
| 350×350×350 | 14×14×14 | 355.6 | 377 | 355.6 | 377 | 279 | 279 |
| 400×400×400 | 16×16×16 | 406.4 | 426 | 406.4 | 426 | 305 | 305 |
| 450×450×450 | 18×18×18 | 457 | 480 | 457 | 480 | 343 | 343 |
| 500×500×500 | 20×20×20 | 508 | 530 | 508 | 530 | 381 | 381 |
| 550×550×550 | 22×22×22 | 559 | - | 559 | - | 419 | 419 |
| 600×600×600 | 24×24×24 | 610 | 630 | 610 | 630 | 432 | 432 |
| 650×650×650 | 26×26×26 | 660 | - | 660 | - | 495 | 495 |
| 700×700×700 | 28×28×28 | 711 | 720 | 711 | 720 | 521 | 521 |
| 750×750×750 | 30×30×30 | 762 | - | 762 | - | 559 | 559 |
| 800×800×800 | 32×32×32 | 813 | 820 | 813 | 820 | 597 | 597 |
| 850×850×850 | 34×34×34 | 864 | - | 864 | - | 635 | 635 |
| 900×900×900 | 36×36×36 | 914 | 920 | 914 | 920 | 673 | 673 |
