Featurer:
Conventional: Grip ring or grooved installation
Japanese bearings & structure
Anti-seismic optical structure
The USA optical elements
Shaft Dia 20-45mm
Monocyclic Pulse:10 - 10000P / R
10 - 12500P / R
| Working Voltage | 10-30V | 5V/8V | Working TEMP | 0℃to+70℃ -40℃to+100℃ | |
| Current Consumption | ≤100mA | ≤150mA | Storage TEMP | -30℃to+80℃ | |
| Power Consumption | ≤3W | Ambient Humidity | 85%(non-condensing) | ||
| Output Signal | complementary | Drive | IP Code | IP54 | |
| Signal Form | AB square wave | AA-BB- square wave | Max RPM | 3000 RPM (max) | |
| Output Current | ≤20mA | Axial & Radial Load | Axial 30N ,Radial 20N | ||
| Rise & Fall Time | ≤1000nS | Weight | ≈1kg | ||
| Output Frequency | ≥100kHz | Maximum Angle Acceleration | ≤10 rad/s | ||
| Amplitude | VL≤1.5VDC | VL≤0.5VDC | Start torque 20℃ | 0.02Ncm | |
| VH≥Vcc-2.5 | VH≥2.5 | Vibration Endurance | Vibrating (50-2000Hz) | ≤100m/s (10g) | |
| A、B Signal Accuracy | Duration of Signal | 1/2T±1/8T | Impact(11ms) | ≤1000m/s (100g) | |
| Signal Phase Difference | 1/4T±1/8T | Case Material | AL+FE | ||
| Isolation | ≥10MΩ | Shaft Material | 2Cr13 | ||
| Voltage Withstand | 500V 1min | Shaft Diameter | Φ30-65mm | ||
| Resolution | 10-2500 PPR | Connection Type | 7.5M Radial Outlet + DB15 plug | ||
