Brand:-
Model:-
MOQ:1 Sets
FP series hydraulic cement foaming machine are based on advanced foreign technology, focus on the domestic actual situation, with our developing and producing experiences, innovatively designed. They have completely independent intellectual property and leading technology on duplex hydraulic driven and full-automatic control.
Features and areas of application:
•small sized but complete performance
•mixing, foaming and pumping in one machine
•single-phase power supply
•applies to small scale scientific research and home floor heating
| Parameter | Specs | |||
| FP02B | FP05B | FP10B | ||
| Delivery Pressure(MPa) | 1 | |||
| Output(m3/h) | 1.5~2 | 3~5 | 8~10 | |
| Max conveying distance(m) | horizontal | 300 | ||
| vertical | 40 | |||
| Power supply type | Single phase | Single phase | three-phase | |
| Total power | 2.3 | 4.5 | 7.7 | |
| Mixer tank capacity(L) | 180 | 200 | 350 | |
| Filling height(mm) | 1300 | 880 | 1000 | |
| Weight(kg) | 480 | 910 | 1000 | |
| Dimension(mm) | 1600*640*1300 | 2100*1340*1390 | 2390*1490*1440 | |
| Feeder size(mm) |
| 2990*760*830 Contact Infomation
