Quick Details

Condition: New Power Type: Electric Place of Origin: Henan, China (Mainland) Brand Name: HAOMEI Model Number: HZS50 Power(W): 110kw Dimension(L*W*H): 33.8mX14.8mX10.8m Weight: 46Ton Certification: ISO,CE Warranty: 12 months After-sales Service Provided: Engineers available to service machinery overseas Capacity:: 50m3/h Main Mixer:: JS1000 Power of Main Mixer:: 37kw Feeding Mode:: Lifting hopper Mixing Time:: 60s Max Aggregate Size:: 60/80mm Discharging Height:: 3.8m(for customers choice) Control Mode:: Automatic Control System/Central Console Control System Control: Fully automatic Cement Silo: 50T,100T available

 Technical parameter  of HZS50 Concrete Batch Plant

Main technical data

Type

HZS50 concrete batch plant

Productivity in theory

50m³/h

Mixer

JS1000

Maximum aggregate diameter

80mm

Aggregate bins volume

3X13m³

Aggregate feeding method

Conveying belt

Batcher

PLD1600

Aggregate weighing

3000kg ±2%

Cement weighing

600kg ±1%

Fly-ash weighing

400kg ±1%

Water weighing

400kg ±1%

Additive weighing

50kg ±1%

Overall dimension(during operating)

        (LXWXH)

33.8mX14.8mX10.8m

Total power

110kw

Total weight

46Ton

Discharging height

3.8m

Control

Fully automatic

Cement silo(optional)

Required on clients' demand, 50T,100T available

Cement screw(optional)

Each cement silo equipped with one φ219 screw
