150m Leg Fixing Type Self Climbing Tower Crane For Wharf , 6 tons

TC6010 tower crane (QTZ80)

1. Specification: TC6010

2. Dimensions: standard section 1,600mmX1,600mmX3,000mm

3. Material: All main chord is in Q345B steel

4. Application: Suitable for construction of medium and high-rise commercial, civil buildings and such large projects as roads and bridges, power stations, etc. as well as construction of large goods yard, wharf, etc.

5. Parameter: Maximum hoisting capacity 6 tons, maximum arm length 60m, maximum independent lifting height 40m, maximum attached height 150m

6. Model number: QTZ80

Quick Detail

1. The tower crane is an outside climbing and self-elevating tower crane with horizontal jib, trolley-luffing and upper rotray.

2. The maximum jib length is 56m, the jib length combination reduces for every 6m and the minimum arm length is 44m.

3. The maximum hoisting capacity is 6 tons.

4. The maximum lifting capacity at a distance of 56m is 1.0 ton.

5. The maximum hoisting moment is 93.36t.m.

6. The maximum independent height is 40m and the maximum attached height is 140m.

7. Hoisting mechanism: Adopting a three-speed motor   24KW for power

Slew mechanism: Adopting a double gyration winding motor  3.7 KWX2 for power

Luffing mechanism: Adopting a double-speed motor    3.3KW for power

8. The mast used monotlithic standard section of 1,600mmX1,600mmX2,800mm or chip standard section of 1,600mmX1,600mmX3,000mm .

9. Tower crane foundation type: Leg fixing type. Stone bolt fixing type

Description:

Our main products are: Topkit tower crane QTZ63(TC5013), QTZ80(TC5610, TC5610A,TC6010,TC6010A), QTZ100(TC6013-6, TC6013A-6, TC6013-8, TC6013A-8), QTZ125(TC6015-8, TC6015A-8, TC6512-10, TC6512A-10), QTZ160(TC7013-10, TC7013-12), QTZ250(TC7520-12, TC7520-16)

Topless tower crane QTZ125(TCP6015-8, TCP6512-10), QTZ160(TCP7013-10, TCP7013-12)

TC6010(QTZ80)Tower Crane is a high-end self-elevating tower crane designed according to the needs of construction for small and medium-sized
