Description:

1. good sealing performance, waterproof, energy-saving

2. material: aluminum alloy

3. color: customization

4. size: customization

                                                        Exploded view

Aluminum louver's frame with professional mold extrusion molding, hollow and curved rib design.

Easy installation and Compressive strength.

It is assembled into the outer frame with the use of the upper and lower beams.

Aluminum louver's underbeam using a special cut water and fetch water

design.professional extrusion mold that to ensure Rainwater does not flow

into the entire form outside.

Aluminum louver's sealing strip have a Specially designed, with the blade slot,it can guarantee between the blade and the blade closed state seal,Play a very good dust, noise and thermal insulation effect.

1.Aluminum louver's Blade using professional extrusion mold, according to the size, can be used with100,130,158,165 ect different specifications.

2.The Blade Design is the blade slot at both ends of the blade.in the middle it is hollow.

3.wall thickness generally is 0.9-1.1mm, it not only ensure the blade toughness and wide but also greatly reduces the overall weight.

1.Aluminum louver's Blade is fixed and transmission by the Stainless steel fixture.

2.the fixture use high-quality 304 #stainless steel, surface is polished.

3.using stainless steel material ensured its toughness, elegant appearance and durable function.

Aluminum louver's blade bracket are fixed with professional riveteds, not only lightweight, but also to ensure the appearance and durability.

Common rivets generally have two materials: Copper and stainless steel.

1.The electric have MCU overload protection function.

2.when there have an obstacle in the opening and closing process it will stop automatically.

3.the motor have strong thrust and pull , small size, low noise, stable operation, beautiful appearance and easy installation ect Feature.

4.Built-in electronic have overload protection,high waterproof function.

5.The motor as a System Driver Widely used in louvers, skylights, side windows, Firefighting Exhaust louver and ventilation louver.

<< Six unique properties: >>

1. Soundproof

When All the leaves off the indoor noise can be reduced by 30 dB or more, air conditioning and refrigeration also can greatly save energy;

2. Ventilation and privacy

When the Blade are adjusted to 15-25 degrees the outdoor can not see inside. while indoor and outdoor air are convectional so the ventilation is good;

3. Dust resistance

When the Blade are adjusted to 45 degrees no rain floated indoors.when the leaves off, closed well, effectively blocking dust;

4. wide field of vision

When the Blade are adjusted to 90 degrees, the maximum field of view can be achieved without any shelter repression;

5.Good Daylighting performance

When the Blade are adjusted to 105 degrees it have a light refraction effect, increase the degree of indoor lighting;

6. prevention of burglary and durable

Aluminum louver has better anti-theft function and shock-resistant function;It Can effectively prevent the oxidation and corrosion so it is durable
