FAT-4A fiber access termination box from greentelftth.com is able to hold up to 4 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.

Features �� Water-proof design with IP-66 Protection level. �� Integrated with splice cassette and cable management rods. �� Manage fibers in a reasonable fiber radius condition. �� Easy to maintain and extend the capacity. �� Fiber bend radius control more than 40mm. �� Suitable for the fusion splice or mechanical splice. �� 1*4 Splitter can be installed as an option. �� Efficient cable management. �� 4 ports cable entrance for drop cable.

Configuration

Fiber Access Terminal FAT-4A Parameter

Material

Size

Max Capacity

Installation Size

Weight

Color

PC+ABS

AxBxC(mm)

SC

LC

PLC

D(mm)

0.8kg

Light Grey

186x116x41

4 Ports

8 Ports

1x4(SC)

195

             Standard Accessories Splice cassette and cable management tool, installation nuts and bolts, protection sleeves, hose clamp, rubber steal for cable entrance.

Optional Accessories Pole ring, Extra lock and key
