Machine FeaturesWindows 7 operation software platform Restart function for power offApplying linear guide line for X,Website:http://www.fhedms.com,Y, Z axis Smart wire speed control Advanced Step Machining Advanced cornor machiningHigh cutting speed High Precision Positioning functionAutocut operation software based on autocad 2005, easy for the begineerUse 0.3mm molybdenum instead of 0.18 mmAutomatic Wire Tension control device Specifications X - Axis Travel 21.65" (550 mm)Y - Axis Travel 17.71" (450 mm)Z - Axis Travel 17.71"(450 mm)Max working part dimension 25.59"x32.67"x11.81"( 650x830x300 mm )U,V axis travel 0.59"x 0.59"(15x15 mm )Positioning precision <0.0001" ( 0.003 mm )Three cutting roughness Ra0.7 Accuracy 0.0003"(0.0075mm)Max loading weight 700 kgMachine Detail Description This kind of wire cut edm machine are widely used for metal cutting process, it can be used for cutting any conductive material. And our wire cut edm machine are widely used for cutting special sharp, small accuracy parts. This wire cut edm machine use Recycling moly wire running system, the wire drum Rotate back and forth. And wire drum speed can be adjusted from 1-12m/s. The slower wire drum running, the better cutting surface roughness can reach. It apply smart frequency conversion system. Wire speed 1-12 m/s, can be automatically adjusted according to processing requirement. It adopt a variety of cutting methods, realize multiple cutting of 1-3 times, and enhance accuracy and surface roughness. Configure with upper and lower dual wires tightening device, achieving consistence of constant tension for upper and lower wires. High rigidity structure of the lathe body is combined with high-grade linear guide and ball screw, imported from Taiwan, which ensures overall quality. Machine body auto parts painting standard, to ensure the stable adhesive for long working life.
