Mechanical facts

temperature range: -40-+60°c
impedance: 75ω
frequency range: DC-1GHz
working voltage: 170 v rms at sea level
withstand voltage: 500 v rms at sea level
contact resistance: center contact: ≤10m&omega
                             outer contact: ≤5mω
insulator resistance: ≥1,000mω
center conductor retention force: ≥0.2n
V.S.W.R: straight ≤ 1.20
right angle ≤1.25
mating life: ≥500 times
