Brand:Solar power system
Model:Solar power system: 10KW system
MOQ:-0 -
Send Inquiry
| MODEL NO.: HDG-10KW (10KW Off grid solar power system) |
| 1. 4800W (300W/36V*16pcs) Polycrystalline silicon Solar panel |
| 2. 10KW/96V sine wave inverter output: Single phase220-240V/50HZ or 110-120V/60HZ |
| 3. 12V/250Ah*8pcs solar GEL battery (8-10 years life) |
| 4. 5KW/96V charge controller, switch box, circuit interrupter and all cables |
| 5. PV array combiner box(4 in 1 out *1pc), lightning protection and reduce cables of connection |
| 6. Overload, over-temperature, over-discharge, short circuit protection |
| 7. Digital LCD display indicates battery capacity status, working power, output power.etc. |
| 8. Battery power priority or The city power priority |
| 9. Max solar panel output power each day:24kwh |
| User Load | System working time |
| 1KW | 24h |
| 2KW | 12h |
| 5KW | 4.8h |
| 10KW | 2.4h |
