Specifications

Operating Speed 0-100 rpm

Number of Circuits 3

Voltage 240 VAC/DC

Current Rating 1 amp /per circuit

Temperature Range -20℃ to +80℃

Contact Material Gold to Gold

Lead Size AWG32 silver plated copper ULR, TeflonR

Lead Lengths 200 mm minimum

Dielectric Strength 500 VAC @50Hz, between each circuit and all other circuits

Insulation Resistance 1000 Megohms @ 500 VDC

Noise 70mΩ max.. d @ 6 VDC50 mA ,(operating at 5 rpm)
